Item	Name of item	Unit	JMU128
			A	B	C
Injection unit	Screw Diameter	mm	38	42	45
	Screw L/D Ratio	L/D	24.3	22	20.5
	Shot size(Theoretical)	cm3	203	253	321
	lnjection weight	g	185	230	292
	Injection Pressure	Mpa	186	152	133
	Screw speed	rpm	0--190
Clamping unit	Clamping tonnage	Kn	1280
	Toggle Stroke	mm	360
	Space Between Tie-bars	mm	420X420
	Max.Mould Thickness	mm	450
	Min.Mould Thickness	mm	160
	Ejector Stroke	mm	140
	Ejector Tonnage	Kn	33
	Ejector Number	n	5
Others	Max.Pump Pressure	mpa	16
	Pump Motor Power	Kw	13
	Heater power	Kw	6.8
	Machine Dimensions(L×W×H)	m	4.8×1.34×2
	Machine Weight	Ton	4.15
	Oil Tank Capacity	Liter	220
