Machine Model：JMU-1600 |
|
|
Item |
Name of item |
Unit |
JMU1600 |
|
A |
B |
C |
D |
|
Injection unit |
Screw Diameter |
mm |
120 |
130 |
140 |
150 |
|
Screw L/D Ratio |
L/D |
26 |
24 |
22.3 |
20.8 |
|
Shot size(Theoretical) |
cm3 |
7043 |
8266 |
9586 |
11006 |
|
Injection Weight |
g |
6408 |
7520 |
8723 |
10015 |
|
Injection Pressure |
Mpa |
166 |
156 |
145 |
126 |
|
Screw speed |
rpm |
0--85 |
|
Clamping unit |
Clamping tonnage |
Kn |
16000 |
|
Toggle Stroke |
mm |
1550 |
|
Space Between Tie-bars |
mm |
1500〜1500 |
|
Max.Mould Thickness |
mm |
1500 |
|
Min.Mould Thickness |
mm |
700 |
|
Ejector Stroke |
mm |
350 |
|
Ejector Tonnage |
Kn |
400 |
|
Ejector Number |
n |
29 |
|
Others |
Max.Pump Pressure |
mpa |
16 |
|
Pump Motor Power |
Kw |
45+45+45 |
|
Heater power |
Kw |
92 |
|
Machine Dimensions(L〜W〜H) |
m |
15〜3.5〜4.2 |
|
Machine Weight |
Ton |
110 |
|
Oil Tank Capacity |
Liter |
2500 | |
|
|
|
